Application:
Refrigerant leakage detection in air conditioningProduct characteristics:
High sensitivity, fast responseDescription
The TX210-Q201 refrigerant gas detection module utilizes a semiconductor gas sensor manufactured using an advanced multi-layer thick-film manufacturing process. This sensor incorporates a filter adsorption layer to mitigate interference from gases like alcohol, resulting in extremely high sensitivity to refrigerant gases. The module undergoes aging, calibration, and testing to ensure excellent consistency and high sensitivity.
Technical specifications
| Model | TX210-Q201 |
| Target Gas | Refrigerant gas R32 |
| Output Data | PWM |
| Working Voltage | 5.0±0.2V DC(No voltage reverse connect protection) |
| Output Data | TTLlevel(200ohm protected resistance inside) |
| Working Current | ≤80mA |
| Warm Up Time | ≤3 min |
| Alarm point | 5000ppm |
| Operating Temperature | 0～50℃ |
| Operating Humidity | ≤95%RH |
| Storage Temperature | —20～60℃ |
| Storage Humidity | ≤60%RH |
| Size | 25×34×14.1mm(L×W×H) |
| Weight | 5g |
Terminal definition
| Pin | Name | Function |
| G | GND | Input power- |
| R | / | / / |
| T | / | |
| O | Output | PWM signal output (need to connect external pull-up resistor) |
| V | 5V | Input power+ |
Application
Used for refrigerant leakage detection in air conditioning and refrigeration systems.
Production workshop
Certificate Qualification
TenSensor, China's first listed gas sensor company,Tensensor can provide more than 100 varieties of six series including：
semiconductor gas sensor
electrochemical gas sensor
infrared gas sensor
dust sensor
pyroelectric sensor
thermopile sensor, etc.
which can be used for more than 200 kinds of gas and infrared, dust and other indicators detection, widely used in the field of security for detecting gas leakage, noxious gas leakage, smog and fire, the field of family, office and factory for detecting HCHO, VOC, CO2, PM2.5 and so on.
Moreover, the solutions for security, household electrical appliances, consumer electronics, smart home, instruments and meters are available.
For more information about TX210-Q201 module, please contact account manager.
